ROVI Products Inc. is a manufacturer and distributor of high quality machine tool products, designed to meet your specifications - service that exceeds your expectations. Expanding Collets, Hardinge® OD Collets & Oversize Collets, Metric Serrated & American Standard Chuck Jaws as well as items from our line of Specialty Tooling and many other items are now available for purchase in our Online Store!
Featured Products - NEW at ROVI!
Gerardi Zero Point Pneumatic Clamping Systems
Fast and Accurate Positioning and Workholding

Rovi Products is now offering the Zero Point quick change solution for workholding on your CNC Vertical & Horizontal Mills. The Zero Point System is a pneumatic operated workholding fixture that offers quick part change over, with repeatable position accuracy of .0002".

Using a pull stud type locator and clamp mechanism, this system allows you to easily configure your own top plate to suit your application.

Pneumatic system advantages:
Due to the simple design, the pneumatic Zero point system only needs a quick connection of air for release of the spring holding mechanism. There is an optional air blast mode for clearing chips. The design provides secure clamping forces of more than 3,300 lb and a holding force of more than 13,000 lb. These fixtures can be used in a variety of applications, including with 4th & 5th axis Rotary devices on Vertical and Horizontal Machining Centers. Due to the unique design, no air lines need to be permanently mounted, which allows clamping and unclamping by using a single air line. This is ideal for rotary applications where permanent air lines can get in the way or on stationary applications where chips can build up, etc.

Features & Advantages:
  • Direct Part Mount via Pull Stud
  • Immediate, accurate and safe positioning and clamping in one single operation
  • All components made of special alloy of steel case hardned and ground
  • Very easy to setup and use.
  • Repositioning accuracy within 0.005 mm
  • Built-in mounting
  • Clamping Force 3300 lbs for Type II, Holding force 13,000 lbs
  • Pneumatic release 7bar
  • Positioning shank with elastic collet
  • Double pull-stud centering for Max rigidity
  • Air cleaning
Click Here for More Information & to Order ZERO POINT Pneumatic Clamps Online
Example application showing 2 Pull Studs (Art.11A) installed to under side of modular vise with 2 Zero Point clamps in dual pallet below, waiting to position and secure the vise.

Call (800) 423-5145 for demonstrations and/or custom ordering

Click Here for More Information & to Order ZERO POINT Pneumatic Clamps Online
